Product Overview
LED wraparound fixtures can be installed in a wide range of applications including basements, corridors, utility rooms, and garages. When choosing your fixture, be sure to look at both the color temperature and the safety rating. Color temperature describes the color of the light produced. Fixtures delivering a 3500 Kelvin light create a welcoming atmosphere. 4000 Kelvin light helps reduce eye strain, while 5000 Kelvin light improves concentration and alertness. Some LED wraparound fixtures have switchable color temperatures, allowing you to toggle between three different Kelvin settings with a switch under the lens. Safety ratings indicate what conditions the fixture can operate safely in. Indoor rated fixtures should only be used in dry locations where no moisture is present. Wraparound fixtures rated for damp locations can be used in areas where moisture is present.
Applications
|
•Warehouses |
•Workshops |
|
•Factories |
•Residential Ceilings |
|
•Storage Facilities |
•Distribution Centers |
|
•Retails |
•Supermarkets |
|
•Warehouses |
•Workshops |
Certifications
Specifications
| Model NO. | TES-DM-WR4FT303540W-3545K-AV | Dimmable | 0-10V |
| Warranty | 5 Years | Equal to | 4-Lamp Fluorescent |
| Input Voltage | 120-277V | CRI | >80 |
| Input Wattage | 40W/35W/30W | Available CCT | 3500K/4000K/5000K |
| Delivered Lumens | 5,200LM/ 4,550LM/ 3,900LM | THD | <20% |
| Efficacy | 130 LM/W | Product Dimension | 47.6*7.08*2.9” |
| Rated Life | >50,000 Hrs | Carton Dimension | 50.0*13.0*9.0” |
| Power Fact | >0.9 | Package | 4pcs/ctn |
| Operating Temp | -40°F to 113°F | Product Weight/pc | 26.00 lb |
| Certifications | UL Damp Locations | Gross Weight/ctn | 28.00 lb |
